Maximum anti-crushing safety by coupling the twin-disk oil-bath clutch with the electronic device and encoder.
As the gearmotor is non reversing, no electric locks need be installed.
Key protected lever release device.
Magnetic limit switch device, simplified installation of limit switch magnets
Designed for height and side adjustable fastening.
Control board, protected by a housing, for simplified programming via display.

Gate Max Weight	600 kg
Power Supply Voltage	230 Vac (+6% -10%) 50 Hz
Electric Motor	Single-Phase , Bi Directional
Absorbed Power	400 W
Absorbed Current	2.15 A
Traction and Thrust	0 to 810 N
Motor Rotation Speed	1400 rpm
Thermal Protection on Motor Winding	120°C
Clutch	Twin-disk in oil-bath
Reduction Ratio	1:30
Operating Ambient Temperature	-20°C to +55°C
Weight with oil	14 kg
Type of Oil	FAAC HP OIL
Gate Speed	9.6m/min
Protection Class	IP44
Dimensions (L×D×H)	275×191×336 mm
Limit Switch	Magnetic
