Range of professional 230Vac electromechanical barriers with speed variator and three-phase induction motor for high frequency of use. Designed and developed to operate in a wide variety of conditions such as large car parks, motorway tollgates with frequent reversing, industrial installations. Three-phase motor with inverter. Oil bath gear motor. Mechanical crankshaft movement (anti-vandalism system) which can deliver fluidity of movement and balance to the bar by also controlling its soft opening and closing. With U-Link protocol for integration with Parking Management or Building Management systems.

Features:

– U-link

– Rolling Code

– Inverter

– Inverter With Three-Phase Induction Motor

– Reduction Unit In Oil Bath

– Crank Handle System

– Three-Phase Induction Motor

– Inductive Encoder

Technical Specifications:

Opening Time (depending on the width of the leaf)	from 4.5 to 6s
Clear Opening	from 4 to 8m
Control Unit	CSB Xtreme
Motor Type	Three-phase asynchronous
Motor Power Supply	230V
Internal Lubrication	In oil bath
Inverter	Yes
Slowdown	Yes
Impact Reaction	Encoder
Locking	Mechanical
Release	Inside The Structure
Frequency Of Use	Very Intensive
MCBF (Mean Cycles Between Failures)	2000000Op
Environmental Conditions	-30 ÷ 60°C
Protection Rating	IP54
